2023 Wonderland RV Hornet 20'06 Rear Door

Capable off roader in a classical layout/floor plan featuring a rear entry door with spacious En Suite, Very large kitchen with lots of drawers and a super comfy L-shape Lounge.
amazing full Off-grid caravan that is powered by a massive Victron under lounge system.
400Ah Lithium with the option to upgrade to 600Ah
Full Van Inverter wired to all GPO's including Aircon - Victron 3000w / 300VA
1000 Watts of Rooftop Solar
DC Charger
Dual Solar Regulators

CHASSIS
6" A-Frame 1950mm & 4" Chassis & 4" Riser
Black Powerdercoated chassis
*4.5T Cruisemaster XT L3 Wireless Suspension
12" Drum Breaks
Stone Deflector
4 Arm Bumper Bar
2 x Jerry Can Holder Rear Bar
*DO45 Hitch by Cruisemaster Recessed & 4.5T Chains
Dual TB10Storage Boxes with 2 Slides & 12v Socket
16" 265/75R16 MPC All Terrain 6x139 ET0
Caravan Jack and Brace
Alko 8" Wide Large Clamp
Drop Down Corner Stabilisers
Single Aluminium Step
Rear Recovery points

ELECTRICAL
Victron Under Lounge Electrical Board
2 x Arizon Lithium Batteries
5 x 200W Solar Panels
3000W Full Van Inverter
2 x30 MPPT
500A Shunt & 30A DC
1 x Grey Anderson Plug & 1 x Yellow Portable Solar input
CS Pressure - 12v Powered Dust Reduction
* 2 x Sirocco fans
*Dexter Stability Control
Fusion Premium Pack & Speakers
Ibis 4 Air Conditioner
23L Mirror Finish Flatbed Microwave
Swift Recessed Rangehood
Safety Dave Reverse Camera & Car Windscreen Monitor
24" Smart TV / DVD
Digital Wind Up TV Antenna
USB/USBC Outlets
TV Points 1 x External TV Bracket & 1 x Internal TV Bracket
Breakaway; Smoke Detector; LPG Detector; Fire Blanket & Fire Extinguisher
6 External Lights inc BBQ Light & Anti Bug Lights
LED 3" Downlights & Tail Lights
12 Pin Tow Plug

PLUMBING
*TRUMA Gas Heater
2 x 100L Fresh Water Tanks
1 x 100L Grey Water Tank
1 x 70L Drinking Water Tank
Checkerplate water tank protectors & plumbing Protection
*Full Oven & 4 Gas Burner Stove
Large 224L DOMETIC Compressor Fridge
External Shower
1 x Gas Bayonet
2 x Gas Bottles
Swift Gas & Electric
1 x Cold Tap on A Frame
Quick Fill & Mains Connection & 1 Separate Filler & Cap
2.6kg Top Load Washing Machine
3 Way Tall Gooseneck Kitchen Tap with Filter
1 piece -fiberglass shower
Thetford Plastic Bowl Cassette Toilet

EXTERNAL
Dibond Marine Grade German Composite Panel
850mm Checker plate Black
Dometic Grey Awning with Black Arms & Awning Support
External Hatch For Entertainment Pack
High Access Tunnel Boot Doors
2 x Large LED Hatches with Fans in Bathroom
2 x Large Roof Hatches
Black Picnic Table
Black 1750x622 Entry Door
Large Double Glazed Windows with Dark Tint

INTERNAL
CNC Ply furniture- precision cut with no gaps
Pillowtop Mattress Queen 6'3"
Roller Blind on Entry Door
Waterfall Benchtop

All our vans have:
-1 piece floor
-1 piece 35mm Composite front & roof & back
-EPS Insulation
- Marine grade composite cladding
